Axial new generation main ventilation fans VО-34R3

3200
Electric drive power, no more than, kW
270
Nominal air feed, m3/s
3410
Operating wheel diameter, mm
750
Rotation frequency, rpm
Description

Main advantages:

  • Working blades are manufactured of high-tensile stamped duralumin.
  • Minimum clearance between the working wheel blades and fan frame provides 88% efficiency.
  • Anti-stall device provides stable operation in every mode of fan working area.
  • Brake prevent spontaneous rotation while electric motor is off.
  • Ejector system decreases bearings temperature and excludes oil spillage from rotor bearing assemblies by creating negative pressure in its spaces.
  • European-made spherical rolling bearings with splined fixation to the shaft.
  • Diffuser with low pressure losing coefficient.
  • Transition from operating fan to reserve one is not more than 8 min.

Ability of manufacturing compact block-modular fan systems, providing 100% air flow reversing.

Characteristics
Rotation frequency, rpm 750
Operating wheel diameter, mm 3410
Nominal air feed, m3/s 270
Nominal static pressure, Pa 4500
Maximum static efficiency 0,84
Electric drive power, no more than, kW 3200
Main fan weight (without electrical equipment), t 40
